TZ220XS026A Drive Motor
Sanci TZ220XS026A Drive Motor is a highly integrated electric drive system with a voltage platform of 540 VDC, rated/peak power of 70/145 kW, rated/peak torque of 150/330 Nm, and rated/maximum speed of 4450/12000 rpm.
The application scenarios of Sanci TZ220XS026A Drive Motor are Device Driving, Electric Drive Axle.
As part of EMAC, DuraMac provides complete powertrain that integrated with DCEC engine, Fast-Eaton clutch, FAST-CAT transmission, DANA axle and Komman air suspension, while the electrification of automobile is the certain future, Duramac also get involved with EV powertrain system.
We provide full life cycle services for all customers, from design to power system supply, from installation to commissioning, from after-sales service training to spare parts supply, from trouble shooting to overhaul technical support.
Advantages of TZ220XS026A Drive Motor
-
Thermal management: water channels are connected, and multiple thermal management systems are integrated.
-
High integration: free up space, can be effectively integrated into various vehicles and industrial equipment, and optimize the layout and performance of the whole vehicle.
-
Simple structural design and easy maintenance: simplify connectors, integrate structure and process, reduce suppliers, and improve product qualification rate.
-
Professional R&D capabilities: through NVM simulation and verification, set vehicle NVM targets, optimize NVH of electric drive system and motor modal design, and perform modal testing, electric drive bench NVH testing, and vehicle NVH testing.
-
Innovative technology: The company actively adopts innovative technologies, such as rotor topology technology, flat wire winding technology, and oil cooling simulation capabilities.
Technical Specifications
| Drive Motor Model: | TZ220XS026A |
| Voltage Platform: | 540 VDC |
| Rated Power: | 70 kW |
| Peak Power: | 145 kW |
| Rated Torque: | 150 Nm |
| Peak Torque: | 330 Nm |
| Rated Speed: | 4450 rpm |
| Maximum Speed: | 12000 rpm |
| Rated Current: | 166 Arms |
| Peak Current: | 320 Arms |
| Motor Weight: | 65.5 kg |
| Motor Size: | Φ 278 mm * 274 mm |
Motor Model |
Voltage Platform |
Rated Power |
Peak Power |
Rated Torque |
Peak Torque |
| TZ220XS013A | 350 VDC | 60 kW | 130 kW | 140 Nm | 320 Nm |
| TZ220XS026A | 540 VDC | 70 kW | 145 kW | 150 Nm | 330 Nm |
| TZ220XS028A | 540 VDC | 60 kW | 120 kW | 150 Nm | 325 Nm |
| TZ220XS020A | 540VDC | 32.5 kW | 70 kW | 225 Nm | 450 Nm |
| TZ220XS017A | 540 VDC | 60 kW | 80 kW | 360 Nm | 560 Nm |
| ——END—— | |||||
The TZ220XS026A specific main parameters are as follows.
The understanding and application of these parameters can help engineers and users better configure, operate and maintain the TZ220XS026A Drive Motor to ensure its optimal performance and safety in actual applications.
|
Model |
TZ220XS026A | TZ220XS028A |
|---|---|---|
| Voltage Platform | 540 VDC | 540 VDC |
| Rated / Peak Power | 70/145 kW | 60/120 kW |
| Rated / Peak Torque | 150/330 Nm | 150/325 Nm |
| Rated / Max. RPM | 4450/12000 rpm | 3820/12000 rpm |
| Rated / Peak Current | 166/320 Arms | 155/310 Arms |
| Motor Weight | 65.5 kg | 55 kg |
| Motor Size | Φ 278 * 274 mm | Φ278 * 274.5 mm |
The TZ220XS026A Drive Motor the specific chart description are as follows.
Charts can more intuitively present the characteristics of the product,understanding the maximum characteristic curve and efficiency MAP can help engineers and users better configure, operate and maintain the TZ220XS026A Drive Motor to ensure its optimal performance and safety in actual applications.
The following is a detailed illustration of the basic dimensions of the TZ220XS026A. Understanding these is critical to many aspects of the design, installation, transportation and maintenance process, and can help ensure the efficiency and safety of the equipment during use.
The specific aspects are as follows:
(1)Suitability assessment: By understanding the dimensions of the drive motor, it can be evaluated whether it can fit into a specific installation space or mechanical structure. This is critical for engineering design and layout to ensure that the equipment can be installed and operated correctly.
(2)Space planning: Basic dimensions can help plan the layout of the equipment, including the spatial relationship with other components or systems. This is important for factory equipment layout, vehicle electrical system design, etc.
(3)Ease of installation: Knowing the size of the drive motor can help prepare appropriate mounting brackets, fixing equipment or develop installation procedures in advance. This helps to simplify the installation process and reduce possible rework or adjustments.
(4)Transportation and storage: Knowing the dimensions also helps plan the transportation and storage of the equipment, ensuring that the equipment is not damaged or the risk of damage during handling and storage is minimized.
Can Quality be Guaranteed?
(1) Rich production experience: We have many years of experience in producing this product, which can match various types of mechanical equipment from 2T to 10T.
(2) Quality management system: Our company has a complete quality management system to ensure that every link meets strict quality standards.
(3) Continuous improvement and feedback mechanism: We focus on continuous improvement, communicate with customers through feedback mechanism, continuously optimize product quality and performance, and ensure that the needs of the market and customers are met.
Is the Price Reasonable?
We are the original manufacturer and can give you the most suitable price. The key to dealing with Chinese suppliers is to find and choose reliable business partners who will not deceive you for short-term business, but aim to establish a long-term career and lifelong partnership. EMAC is one of the reliable partners. We will not pursue short-term high profits, but we care about our decades of good reputation. Our cooperation with all business partners is not only as suppliers and customers, but also as close friends and brothers.
What should I do if I don’t Understand the Product?
You can unconditionally explain your needs to us. We have a professional team that uses simple and clear language to explain the characteristics and advantages of the product and help you choose the right motor to match the best controller. If you need further support or explanation, we are always available to help and explain the relevant content to help you solve the problem.
How to Place an Order?
You can confirm the product by connecting with our sales, or you can choose to contact us through wahtspp or your email, and we will guide you to complete the order process.
Note: All Above Data are Just for Reference, All Data Might Change Without Notices or Updates, Please Contact Our Sales Team to Confirm All Details Via WhatsApp or Email.
